• Connector Type: XT60 (2 Male to 1 Female – 2M1F)
• Configuration: Connects 2 battery packs in series to 1 output
• Material: Nylon housing with gold-plated copper contacts
• Wire Type: 14AWG flexible silicone wire
• Wire Length: Typically 10–15 cm per branch
• Current Rating: Up to 60A continuous
• Voltage Rating: Up to 500V
• Temperature Range: -20°C to 120°C
• Dimensions:
  • XT60 Connector Body Length: ~21 mm
  • XT60 Connector Body Width: ~17 mm
  • XT60 Connector Height: ~8 mm
  • Pin Diameter: ~3.5 mm

Features:

• Gold-plated contacts for low-resistance, high-conductivity connections
• Flexible silicone wire for easy routing and installation
• Durable nylon housing for mechanical and thermal reliability
• Ensures safe, stable series connections for battery packs
